Half Rack Unit Size

A rack unit is a unit of measure used to describe the height of a server network switch or other similar device mounted in a 19 inch rack or a 23 inch rack.

Half rack unit size.

The size of a piece of rack mounted equipment is usually. Mounting a half rack size unit question motu audioexpress it included a kit for mounting two motu half rack units in a standard 19 rack. Rack size is a measure in electronic industries alliance eia standard rack units rack u and a single u is equivalent to 1 75in. A 23 inch 580 mm rack is used for housing telephone primarily computer audio and other equipment though is less common than the 19 inch rack.

I d like to mount just the one unit in a rack but the included ears are not large enough. The size denotes the width of the faceplate for the installed equipment. One rack unit is commonly designated as 1u. A single rack unit is exactly 1 75 44 45 mm in height although many manufacturers will make their equipment slightly smaller than this to ease installation into racks where things were.

The rack unit is a measure of vertical spacing and is common to both the 19 and 23 inch racks. No other hardware is required. A u or rack unit is a measurement of the height of a piece of computer or network gear that is designed to fit into a standard 19 or 23 rack. Like any basic form of measurement within the colocation industry there is a standard size for servers.

For the sake of standardization the size of a single u or ru is 1 75 inches in height 44 45 mm. This size of each server is called a u or a ru unit or rack unit. Server racks and cabinets are available in different sizes so you can ensure that you have ample space to accommodate current and future expansion plans. Rackmout kit for half rack size units this coupler joins two 1 2 wide space 1 ru high products.

The extron half rack shelf system and related accessories is designed for applications utilizing one half rack width and smaller products the compact 1u half rack width size allows the mounting of half quarter and eighth rack products in space constrained furniture such as lecterns and cabinets that are not wide enough to support the mounting of full width 19 rack shelves or. Both products must be equipped with rack ears. Coupler includes 8 rack mount screws 10 32 x 3 4. Similarly 2 rack units are 2u and so on.

The rack mount coupler may only be used with 1 2 wide products having rack ears. One rack unit is 44 45 mm 1 75 in high.
