Ibm T42 Rack Pdu

Nine different power cord features.

Ibm t42 rack pdu.

The choice of which initial pdu is ordered for the rack will determine which additional pdu features may be ordered for the rack either in the original rack order or in a later mes order. 42u of rack space 42u of rack space is needed to scale out four building blocks. Model abstract 7014 t42 the ibm 7014 rack model t42 is a 2 0 meter rack that will address the special requirements of customers who want a enclosure to house their equipment. The following chart shows the allowable pdu combinations within a single t00 or t42 rack.

Power distribution units pdus are required with 7014 t00 7014 t42 ibm racks and optional with 7014 b42 0551 0553 and 0555 ibm racks except with a 0578 or 0588 expansion unit if a pdu is not defaulted or ordered a power cord is provided with each individual rack mounted drawer for connection to a country specific utility mains receptacle or uninterruptible power supply. The following figure shows the four vertical pdu locations in 7014 t00 7014 t42 7014 b42 and 7965 s42 racks. Standard 19 inch rack width the standard rack width is 19 inches. Ibm 42u server rack cabinet enclosure complete with side panels 2 ibm pdus 39y8925 condition used brand ibm part number 7014 t42 no keys included rack specifications height 2015 mm 79 3 in width 644 mm 25 4 in with side panels depth 1 098 mm 43 3 in with front and rear doors weight 290 kg 639 lb.

The t42 provides 42 eia units 42u of usable space. Ibm 7014 t42 42u server network rack cabinet enclosure 41v0087 with pdu s. Power distribution units pdus are required with 7014 t00 7014 t42 ibm racks and optional with 7014 b42 0553 and 0555 racks except with a 0578 or 0588 expansion unit. Use the following rack and power distribution unit pdu requirements to make appropriate selections for the scaled out system.

Home racking server rack cabinets and rack server enclosures ibm 7014 t42 42u server network rack cabinet enclosure 41v0087 with pdu s. Standard 1000 mm rack depth the typical rack depth that is used in most. Because of its height special shipping and handling procedures may be required in some cases. Power distribution unit vertical locations.

The 7953 94x and 7965 94y racks have six vertical pdu locations. If a pdu is not defaulted or ordered a power cord is provided with each individual rack mounted drawer for connection to a country specific utility mains receptacle or.
